Connect. Integrate. Simplify.
Advanced E-Bridge Next Technology
Toshiba’s next-generation e-BRIDGE architecture features an embedded web browser, 4 GB RAM and the Toshiba secure 320 GB hard disk drive enabling the MFP to easily drive Toshiba’s internally developed solutions or even third-party applications.
Create a lasting impression with high-quality document output in colour and monochrome with a resolution of up to 1200 dpi x 1200 dpi.
A simple touch of a button is all it takes to start an automated workflow powered by the optional dual scan document feeder.
Compact Stylish And Fully Customisable
A large 10.1 ” Industry-largest touch screen is your gateway to document handling which has never been easier. Size and order of icons as well as the background image can be customised. Enjoy the unique experience of working with a system that understands what you want.
Complete Peace Of Mind
Toshiba keeps the security of your business top of mind. Like a self-encrypting Toshiba Secure HDD that provides top level security. You can also add optional security functions to make the system compliant with IEEE2600.1 and meet the EAL3 Common Criteria requirements. IPsec is also available to securely encrypt data sent to and from the MFP.
Seamless Connectivity To Industry Standard Applications
The optional e-BRIDGE Plus connectors for Microsoft OneDrive, Google Drive and Dropbox let you send your documents directly to or print from these cloud services via the MFP.
Built In Convenience
This MFD has been designed to accommodate a range of optional card readers, not only provides fast and convenient access to your print jobs but also increases data security. The e-STUDIO3515AC series can also be optioned with a dedicated draw for printing envelopes with ease.
Responsibility For The Planet
Innovation ensures that our environment is part of the equation, which is precisely what we do at Toshiba. This state-of-the-art MFP is RoHS compliant and uses recycled plastics and a low-power Super Sleep Mode to save resources.
ENERGY STAR Tier 2 compliance means this system meets the latest, most stringent environmental requirements.
Specifications:
General
Print & Copy Speed:
35 ppm (A4)
18 ppm (A3)
Warm-up Time: Approx. 12 seconds from low power mode
Paper Size & Weight:
Cassette 1: A5R-A3, 60-256 g/m²
Cassette 2: A5R-320 x 460 mm, 60-256 g/m²
Bypass: 100 x 148 mm-320 x 460 mm, 52-280 g/m², banner paper (up to 305 x 1,200 mm, 90-163 g/m²)
Paper Capacity:
2x 550 sheets (Cassettes), 1x 100 sheets (Bypass)
Maximum: 3,200 sheets
Inner Output Tray: 400-sheet capacity
Automatic Duplex: A5R-305 x 457 mm, 60-256 g/m²
Controller Type: Toshiba e-BRIDGE Next
Control Panel: 26 cm (10.1") Multi-Touch Colour Panel
Memory: Toshiba Secure HDD 320 GB, 4 GB RAM
Interface: 10Base-T/100Base-TX/1000Base-T,
High-Speed USB 2.0, WLAN* (IEEE802.11b/g/n), Bluetooth, Wi-Fi Direct
Dimensions & Weight: 585 x 641 x 787 mm (W x D x H), ~ 78 kg
Print
Resolution:
600 x 600 dpi, 5 bit
1,200 x 1,200 dpi, 2 bit (equiv. 3,600 x 1,200 dpi) with PostScript driver only
Page Description Languages: PCL5e, PCL5c, PCL6 (PCL XL), XPS, PDF and PostScript 3 compatible
Supported Systems: Windows 10/8.1/7/Server 2008 (32/64 bit), Windows Server 2016/Server 2012 R2/Server 2012/Server 2008 R2 (64 bit), Mac OS X 10.6.8-10.13, Linux/Unix, Citrix, Novell SLES, SAP, AS/400
Network Protocols: TCP/IP (IPv4/IPv6), IPX/SPX, EtherTalk, NetBios over TCP/IP
Colour Modes: Auto-Colour (ACS), Colour, Twin Colour, Monochrome
Colour Settings: ICC profile colour management, Brightness, Saturation, Contrast, Colour Balance
Mobile Printing: e-BRIDGE Print & Capture, AirPrint, Mopria Print Service, Google Cloud Print
Print Functions: Universal Printer Driver, Driver Templates, Driver plug-ins, Print from USB, Hold print, Tandem printing, E-Mail direct printing
Scan
Resolution: Maximum 600 x 600 dpi
Scan Speed: Reversing Automatic Document Feeder: up to 73 ipm (300 dpi) in colour and monochrome
Dual Scan Document Feeder: up to 240 ipm (300 dpi) in colour and monochrome
Scan Modes: Auto-Colour (ACS), Colour, Greyscale, Monochrome
File Formats: JPEG, Multi/Single Page TIFF/XPS/PDF, Secure PDF, Slim PDF, PDF/A (A-1, A-2), Searchable PDF (and other formats like DOCX, XLSX)
Scan Functions: WS Scan, Scan to USB, Scan to E-Mail, Scan to File (SMB, FTP, FTPS, IPX/SPX, Local), Meta Scan, OCR scan, Scan to Box (e-Filing), WIA, TWAIN
Copy
Resolution:
Scan: 600 x 600 dpi
Print: 600 x 600 dpi, 5 bit, equiv. 2,400 x 600 dpi with smoothing (monochrome only)
First Copy Output Time:
Colour: Approx. 7.8 seconds
Monochrome: Approx. 5.9 seconds
Zoom: 25-400% (platen), 25-200% (RADF/DSDF)
Copy Modes: Text, Text/Photo, Photo, Printed Image, Map, Image Smoothing
Colour Modes: Auto-Colour (ACS), Full Colour, Twin Colour, Mono Colour, Monochrome
Colour Settings: Hue, Saturation, Colour Balance, RGB adjustment, 5 one-touch modes
Copy Functions: Electronic Sort, Rotate Sort, ID Card Copy, Edge Erase, 2-in-1 / 4-in-1 mode
Fax
Communication: Super G3, G3 - (opt. 2nd line), Internet Fax T.37
Transmission Speed: Approx. 3 seconds per page
Compression: JBIG, MMR, MR, MH
Fax Memory: 1 GB Transmission/Reception
Network-Fax: Driver for Windows 10/8.1/7/Server 2008 (32/64 bit), Windows Server 2016/Server 2012 R2/Server 2012/Server 2008 R2 (64 bit)
Incoming Fax Routing: To shared folders (SMB, FTP, IPX/SPX), E-Mail, e-Filing
System & Security
Device Management: e-BRIDGE Fleet Management System, TopAccess for remote administration and configuration
System Features: e-Filing document server for secure storage, Document distribution and Print-on-Demand (1 public box, 200 user boxes), 12,060 one-touch templates for storage of personalised settings or workflows, Scan/Fax Preview, RIP-while-Print, e-BRIDGE Open Platform*, Embedded Web Browser, Job Skip, PCL Barcode printing, e-BRIDGE Plus embedded apps
Accounting & Security: Role Based Access, LDAP support, 1,000 department & 10,000 user codes, Card Reader, Private print, Standard data encryption with Toshiba Secure HDD, Data Overwrite Enabler, IP and MAC address filter, Port filter, Support of SSL and IPsec protocols, IEEE802.1x support, IEEE2600.1 compliant, Scan to Secure PDF, Pull-printing
